Proel's new TPRMARKII series features a new and unique design. The enclosures are made with 15mm quality birch plywood and feature new high performance woofers, drivers and horns to create new, extra-ordinary sounds. All models are fitted with an innovative kick-proof grille, and finished with three coats of anti-scratch paint. Newly developed European low frequency drivers reduce the power compression effect. Electronically protected, ferrofluid-cooled European 1¡± compression drivers offer improved HF response. A new, unique elliptical horn maintains precise control of 90¡ÆHx60¡ÆV constant coverage dispersion, assuring uniform HF spread and delivering an incredibly natural sound. The TPRMARKII speakers are available in passive or bi-amplified versions. All power amplifiers are fitted with thermal, DC voltage and short-circuit protection; also provided are subsonic filter, soft start and 2-band equalizer. Two independent input channels allow maximum connection capability (XLR and Jack 1/4¡±); a further pre-amp XLR output enables link signal send.

Datasheet
System type :
2-way vented enclosure
Nominal Impedance :
4 ohm
Input power rating (AES) :
250 W
Input power rating (peak) :
500 W
Frequency response :
65 Hz - 20 KHz (+ 6 dB, -6 dB)
Sensitivity :
98 dB @ 1W/1m
Maximum (peak) Output :
125 dB @ 1m
Low Frequency Device :
12" woofer
High Frequency Device :
1" compression driver
Coverage Angle H. (-6 dB) :
90¡Æ
Coverage Angle V. (-6 dB) :
60¡Æ
Flying System :
3 x M10 - top, rear
Connectors :
2 x SPK4MP linked
Construction :
15mm birch plywood
Weight :
17.5 kg (38.588 lb)
Dimensions (W x H x D) :
39.5 x 58.5 x 36 cm
Accessories
NAME
DESCRIPTION
Adjustable metal wall-mount bracket for loudspeakers TPRK12P, TPRK12BA
Heavy duty TNT cover for TPRK loudspeakers.
